Merrytek Dry Contact Series Sensors support PIR infrared motion detection or microwave radar presence detection, meeting diverse application needs. With a unified interface and stable signal output,can be flexibly integrated into smart control systems for offices, hotels, warehouses, and various other scenarios.
—Non-polarity design for flexible wiring and improved installation efficiency.
—High security,suitable for industrial and safety applications with strict reliability requirements.
—Strong compatibility: the dry contact interface is more stable and reduces the risk of device damage from incorrect wiring.
—Drill hole：Φ50-55mm,Flush mounting
—Input:12-24V DC
—4th generation Merrytek human presence sensor，available configure the parameters via Merrytek bluetooth program.
—24Ghz mmwave radar+daylight detect,FMCW technology for human presence detection.
—Mounting height 2.5-4m,max detection radius (motion/micro-motion/presence): 4m
—Drill hole：Φ45mm,Flush mounting and surface mounting available
—Input:12-24V DC
—24Ghz mmwave radar+daylight detect,FMCW technology for human presence detection.
—Mounting height 2.5-4m,max detection radius (motion/micro-motion/presence): 3-4m
—available configure the parameters via MH10 remote.
—Drill hole:Φ35mm supper mini size，Flush mounting，uses a self-developed ultra-flat lens, it is hidden and aesthetically for installation
—Input:12-24V DC
—PIR infrared motion detect+daylight detect,accurately detects human movement and on-demand dimming
—Mounting height 2.5-4m,max motion detection radius : 6-7m
—available configure the parameters via MH10/MH18 remote.
—Ultra-slim body, surface ceiling mounting (no cutting required)
—Input:12-24V DC
—PIR infrared motion detect+daylight detect,accurately detects human movement and on-demand dimming
—Mounting height 2.5-4m,max motion detection radius : 2.5-4m
—available configure the parameters via MH10 remote.
—Drill hole:Φ55mm, 3-in-1 installation: flush mounting / surface mounting / EU 86mm box mounting
—Input:12-24V DC
—PIR infrared motion detect+daylight detect,accurately detects human movement and on-demand dimming
—Max mounting height 10m,max motion detection radius : 4-5m
—available configure the parameters via MH10 remote.
—Protection class up to IP54 when surface-mounted with casing
—Drill hole:Φ65-70mm,Flush mounting
—Input:12-24V DC
—PIR infrared motion detect+daylight detect,accurately detects human movement and on-demand dimming
—Max mounting height 10m,max motion detection radius : 4-5m
—available configure the parameters via MH10 remote.
Merrytek Dry Contact Series Sensors offer both infrared and radar detection options, suitable for low mount, high mount, and various installation scenarios. They can be smoothly integrated into existing smart control systems with low cost and high stability,Cost-effective choice for smart renovation projects.
